Synco XVision HD
The Synco XVision HD is a wireless video transmission system for HDMI video sources. This transmitter and receiver set enables real-time video transmission with a range of up to 300 meters and supports video formats up to 1080p60.
With advanced H.265/HEVC video encoding, the system compresses data while ensuring smooth playback. A latency of just 40 ms allows fast real-time feedback. XVision uses advanced low-power chips and intelligent energy management. Optimized heat dissipation and smart adjustments ensure long-lasting, efficient operation.
The Synco Link App not only supports real-time monitoring but also provides essential control indicators.
The large XVision display shows the device status in real time. Thanks to its intuitive button design, even beginners can operate it with ease. The device supports automatic pairing memory, enabling it to reconnect automatically on startup. An NP-F battery slot and USB-C power input eliminate the need for external adapters, ensuring flexible power supply on the go.
XVision features a slim foldable antenna and a lightweight 119 g body. Thanks to its compact size, it fits easily in a pocket and can be carried anywhere.
The XVision HD set is available with one transmitter and a choice of one, two, or four receivers.
Features:
- Wireless Full HD video transmission system
- Real-time monitoring up to 1080p60
- Up to 300 m transmission range
- H.265/HEVC video encoding
- 40 ms latency
- Intelligent power management
- Real-time device status display
- Flexible power supply for mobile use
Tech Specs:
- XVision HD Transmitter:
- 300 m transmission range
- HDMI input/output
- Power supply: USB 5V / NP-F battery
- Max. power consumption: 2 W
- HDMI input specification: 720p@50/60, 1080p@24/25/30/50/60
- Output specification: 720p@50/60, 1080p@24/25/30/50/60
- Transmission band: 5.180 – 5.825 GHz
- Transmission power: 20 dBm
- Latency: 40 ms
- Dimensions: approx. 10.2 × 6.3 × 3.3 cm
- Weight: approx. 119 g
XVision HD Receiver:
- 300 m transmission range
- 2× HDMI output
- Power supply: USB 5V / NP-F battery
- Max. power consumption: 2 W
- Output specification: 720p@50/60, 1080p@24/25/30/50/60
- Transmission band: 5.180 – 5.825 GHz
- Transmission power: 20 dBm
- Latency: 40 ms
- Dimensions: approx. 10.2 × 6.3 × 3.3 cm
- Weight: approx. 119 g
What's in the box (1TX+1RX/1TX+2RX/1TX+4RX):
- 1x Transmitter
- 1x/2x/4x Receiver
- 2x/3x/5x USB Type-C Cable
